Engineering overview
Heavy-duty two-post parking lift
The complete system and its hydraulic drive, mechanical locking point and platform frame connections are presented as one coherent equipment study.
Two-level parking lifts
Heavy-Duty Two-Post Parking Lift
Heavy-Duty Two-Post Parking Lift is the strongest two post simple parking lift, offering 3200kg capacity to stack SUV, van, MPV, pickup, etc. 2 parking spaces are offered on one existing space, suitable for permanent parking, valet parking, car storage, or other places with attendant. Operation can be easily made by a key switch panel on control arm. The feature of post sharing allows more installations in limited space.
YFYS engineered parking systems3200kg/7000lbsLifting capacity
2100mm/83"Lifting height
2100mm/83"Usable platform width
System overview
Engineered for practical parking capacity.
Heavy-Duty Two-Post Parking Lift is the strongest two post simple parking lift, offering 3200kg capacity to stack SUV, van, MPV, pickup, etc. 2 parking spaces are offered on one existing space, suitable for permanent parking, valet parking, car storage, or other places with attendant. Operation can be easily made by a key switch panel on control arm. The feature of post sharing allows more installations in limited space.
Product highlights
Heavy-Duty Two-Post Parking Lift is the strongest two post simple parking lift, offering 3200kg capacity to stack SUV, van, MPV, pickup, etc. 2 parking spaces are offered on one existing space, suitable for permanent parking, valet parking, car storage, or other places with attendant. Operation can be easily made by a key switch panel on control arm. The feature of post sharing allows more installations in limited space.
Lifting capacity 3200kg -Car height on ground up to 2050mm. -Platform width up to 2500mm. -Double hydraulic cylinders, direct drive -Synchronization chain keeps platform level under all conditions -Mechanical anti-falling locks enable multiple stopping heights. -Electric lock release provides easier operation. -24v control voltage avoids electric shock -Galvanized platform, high-heel friendly -Bolts & nuts passing 48hrs Salt Spray Test. -Akzo Nobel powder coating provides long lasting surficial protection
TUV compliant, which is the most authoritative certification in the world Certification standard 2006/42/EC and EN14010
* Twin telescope cylinder of German structure
Germany's top product structure design of the hydraulic system, the hydraulic system is stable and reliable, maintenance free troubles, service life than the old products doubled.
Technical data
Model specifications.
YFYS engineering reference data. Final project values should be confirmed against the approved layout and local code requirements.
- Model
- Heavy-Duty Two-Post Parking Lift
- Lifting capacity
- 3200kg/7000lbs
- Lifting height
- 2100mm/83"
- Usable platform width
- 2100mm/83"
- Power pack
- 2.2kw hydraulic pump
- Available voltage of power supply
- 110V-480V, 1/3 Phase, 50/60Hz
- Operation mode
- Key switch
- Operation voltage
- 24V
- Safety lock
- Dynamic anti-falling lock
- Lock release
- Electric auto release
- Rising / descending time
- <55s
- Finishing
- Powdering coating
Product engineering
Heavy-Duty Two-Post Parking Lift, examined in detail.
Original unbranded engineering visuals developed from the product's structural and component references.
Application planning
Designed around the site, vehicle, and operating model.
Equipment selection depends on access rules, clear dimensions, vehicle weights, user volume, and whether each vehicle must remain independently accessible.
Explore project applicationsProject resources
Confirm the system against your site conditions.
